Automatic Vertical Food Packing Machinery XBIV-420

Application: Small grain and good fluidity powder:for sugar,salt,rice,coffee,gingeli,nonosodium glutamate. Technical parameters: TypeXBIV-420Bag length60-300mm(L)Bag width60-200mm(W)Max. width of roll film420mmPacking speed5-120bags/minMeasuring range1200mlx2(Max)Air consumption0.65MpaGas consumption0.5m³/minPower voltage220VAC/50HZPower2.2KWDimension(L)2050x(W)1450x(H)1270mmDeadweight of machine800kgs Technical characteristics: 1.Simens PLC control with suitable,reliable biaxial high accuracy output and color touch screen,bag-making,measuring,filling,printing,cutting,finished in one operation. 2.Slanting packaging,very useful to protect for the breakable products. 3.Box-packaging bag is more nicety. 4.Servo motors control the carrying film,high precision orientation,size more nicety. 5.External film releasing mechanism:simpler and easier installation of packing film. 6.The process of vertical sealing can adjust the volume deviation automatically,greatly reduce labor intensity. Packing machinery,food packing machine,packing machine.
